MPO MTP OM4 Fiber Cable, 8 Fiber Multimode MPO/MTP Trunk Cable

Product Overview

The Luleey MPO MTP OM4 Fiber Cable is an 8-fiber multimode trunk cable designed for high-density optical network environments. It provides a direct MPO/MTP-to-MPO/MTP connection between patch panels, fiber cassettes, optical modules, distribution frames, and backbone cabling systems.

As an 8 Fiber MPO Cable, this product helps reduce cable congestion by combining multiple multimode fiber channels into one compact MPO/MTP interface. Compared with using several individual duplex patch cords, an MPO Trunk Cable improves rack organization, simplifies installation, and supports cleaner cable routing inside cabinets and data center racks.

This OM4 Multimode Cable is suitable for short-distance high-speed optical transmission, especially in 40G/100G indoor network environments. OM4 fiber provides higher bandwidth margin than OM3 and is often selected for demanding multimode cabling systems where stable transmission and future upgrade flexibility are important.

Although the current product URL includes “Female to Female,” this Luleey MPO MTP Trunk Cable should be described as a configurable MPO/MTP cable because Connector A and Connector B can be selected as male or female, with UPC or APC polish options available. This makes the product page more accurate for project-based orders and avoids limiting customer understanding to only one connector configuration.

Features

• 8-fiber MPO/MTP trunk cable design
• OM4 50/125μm multimode fiber construction
• Connector A configurable as MPO/MTP male or female
• Connector B configurable as MPO/MTP male or female
• UPC or APC polish options available for both ends
• MPO Type A, Type B, and Type C polarity options
• Suitable for 40G and 100G indoor multimode links
• Designed for efficient 8-fiber parallel optics deployment
• Compatible with MPO/MTP patch panels, cassettes, and transceiver systems
• Low insertion loss for stable optical transmission
• LSZH jacket for safer indoor deployment
• Aqua jacket for easy OM4 multimode identification
• Factory tested by Luleey for optical performance
• Available in multiple cable lengths for flexible deployment

Applications

• Data Center Cabling
• 40G and 100G Multimode Fiber Networks
• Parallel Optics Cabling
• Enterprise Network Rooms
• Cloud Computing Infrastructure
• MPO/MTP Backbone Cabling
• Optical Distribution Frames
• Fiber Patch Panels and Cassettes
• LAN and SAN Infrastructure
• High-Density Multimode Fiber Deployment

Specifications

Connector Configuration Notes

This MPO MTP OM4 Fiber Cable should not be described only as a Female-to-Female cable because the product supports multiple connector configurations.

Available connector options include:

For standard OM4 multimode data center cabling, UPC is commonly used. APC should be selected only when the connected MPO/MTP interface and optical system require APC polish. To avoid mismatch, engineers should confirm connector gender, polish type, and polarity before ordering.

Why Use an 8 Fiber MPO MTP OM4 Fiber Cable?

An MPO MTP OM4 Fiber Cable is useful when network engineers need high-density multimode backbone cabling with cleaner cable routing and faster deployment.

The 8-fiber design is especially suitable for 40G SR4, 100G SR4, and other parallel multimode applications where 8 active fibers are commonly used. Compared with 12-fiber cabling, an 8 Fiber MPO Cable can reduce unused fiber channels and make the link design more efficient.

For data centers and enterprise network rooms, the Luleey MPO Trunk Cable provides a practical way to connect high-density MPO/MTP infrastructure while keeping racks cleaner and easier to maintain.

Why OM4 Multimode Cable Matters

OM4 Multimode Cable is designed for high-speed short-distance optical transmission. It is commonly used with 850nm multimode optics in modern data center and enterprise network environments.

Compared with OM3, OM4 Fiber provides higher modal bandwidth, making it a stronger choice for projects that require better link margin, higher-speed multimode transmission, or future network upgrade flexibility.

The Luleey MPO MTP OM4 Fiber Cable helps engineers build structured multimode fiber links with stable optical performance and flexible connector configuration options.

Understanding MPO Polarity

MPO polarity defines how fibers are mapped from one end of the cable to the other. Selecting the correct polarity is essential for proper transmit and receive alignment.

Before ordering, engineers should confirm the required polarity based on the optical module, cassette, patch panel, and cabling design.

8 Fiber vs 12 Fiber MPO Trunk Cable

Both 8-fiber and 12-fiber MPO trunk cables are useful, but they are selected for different cabling scenarios.

Choose the 8 Fiber MPO Cable when your link design uses 8 active fibers or when you want to avoid unused fiber channels.

Choose the 12-fiber version when your cabling design requires higher fiber count distribution or compatibility with 12-fiber MPO infrastructure.

OM3 vs OM4 MPO Trunk Cable

OM3 and OM4 are both multimode fiber types, but they are usually selected for different performance requirements.

Choose OM4 when the project requires stronger bandwidth performance, better transmission margin, or improved flexibility for future high-speed upgrades.

FAQ

What is an MPO MTP OM4 Fiber Cable?

An MPO MTP OM4 Fiber Cable is a high-density multimode fiber cable that uses MPO/MTP connectors and OM4 fiber for short-distance optical transmission.

Is this cable only Female to Female?

No. Connector A and Connector B can be selected as MPO/MTP male or female. The page should not describe the product only as Female-to-Female when multiple connector options are available.

Can Connector A and Connector B use UPC or APC?

Yes. Connector A and Connector B can be selected with UPC or APC polish options depending on project requirements.

What is this 8 Fiber MPO Cable used for?

It is commonly used for data center cabling, 40G/100G multimode links, parallel optics, MPO/MTP backbone cabling, patch panels, and fiber distribution systems.

Is this an OM4 Multimode Cable?

Yes. This cable uses OM4 multimode fiber, typically 50/125μm, for short-distance high-speed optical transmission.

What polarity options are available?

Type A, Type B, and Type C polarity options are available depending on the network cabling design.

What is the difference between MPO male and MPO female?

MPO male connectors include guide pins, while MPO female connectors do not include guide pins. The correct gender depends on the mating interface.

Should I choose UPC or APC for OM4 multimode cabling?

UPC is commonly used for standard OM4 multimode data center cabling. APC should be selected only when the connected system requires APC polish.

What is the difference between OM3 and OM4?

OM4 provides higher bandwidth margin than OM3 and is often selected for more demanding multimode network designs.

Can Luleey provide custom cable lengths?

Yes. Luleey can provide different cable lengths and connector configurations based on project requirements.

Why choose Luleey MPO Cable assemblies?

Luleey MPO Cable assemblies are designed for stable optical performance, clean cable management, and reliable deployment in data center cabling, enterprise networks, and high-density multimode fiber environments.
