10GBase-T SFP+ to RJ45 Copper Module 30m/80m/100m,sfp module

Name: 10GBase-T SFP+ to RJ45 Copper Module 30m/80m/100m,sfp module - LuLeey.com | One-stop Optical Fiber Product Supplier
SKU: 10GBASE-T
Availability: InStock
Rating: 5.00 (14 reviews)

EUR €34.20 EUR €47.03Price range: EUR €34.20 through EUR €47.03

Rated 5.00 out of 5 based on 14 customer ratings

14 reviews

Insert port

Data rate of SFP Module

Distance (Chips)

Compatible brands

Clear

SKU: 10GBASE-T Category: SFP-T (1G/2.5G/10G) Tags: 10G, 10gbase-t, bcm84891, CUX3510, CUX3610, sfp module, sfp to rj45, SFP+

Add to wishlist

High-speed Connectivity: Experience lightning-fast Ethernet speeds with our 10GBase-T sfp module
Easy Conversion: Our SFP to RJ45 module delivers seamless photoelectric conversion for hassle-free Ethernet connections.
Full Brand Compatibility: To work with following brands, please choose Cisco:Accton, Avocent, Broadcom, BlueCoat, Cumulus, Chelsio, Centec, D-LINK, Edgecore, F5, Fortigate, Ixia, Linkysys, Mikrotik, Netgear, Netapp, Sundray, Supermicro, Solarflare, Ubiquiti(UBNT), Wayos, Xilinx, Zyxel
Durable Design: Constructed with a zinc alloy casing, our module offers excellent heat dissipation and can self-adapt to various Ethernet speeds, including 10G/5G/2.5G/1G, sfp to rj45
Extended Reach: Our module boasts a range of up to 30m/80m/100m, providing reliable connectivity over long distances.
sfp to rj45, Low temperature working module

Guaranteed Safe Checkout

1~3 Year Warranty | 15-Day Returns | 30-Day Exchange

Description

10GBASE-T SFP+ Transceiver Module (Copper, RJ-45) 10G BASE-T SFP+ compatible SFP+ transceiver provides 10GBase-T throughput up to 30m/80m/100m over cat6a/cat7 copper cable via RJ45 connector.Suitable for switches, routers, firewalls, network cards, servers, storage devices, fiber optic transceivers, and other devices..

About General brand: Compatible with Cisco, Ruijie, ZTE, TP-LINK, Hikvision, Netgear, Mikrotik, ASUS, Boda, Tenda, Mercury, netLINK, UBIQUITI, Banana Pi

About Chips

Brand	Chips	Transfer Rate	Cable Distance	Power Consumption
LuLeey	Marvell 88X3310	SFP+ 10G	30m	2.31 W
LuLeey	TAIWAN CHIPS	SFP+10G/5G/2.5G	30m	2.65 W
LuLeey	Broadcom BCM84891L	SFP+ 10G/5G/2.5GSFP 1G	80m	1.88 W
LuLeey	Broadcom BCM84891L	SFP+ 10G/5G/2.5GSFP 1G	100m	1.92 W
LuLeey	Marvell CUX3510	SFP+1.25G/2.5G/5G/10G	30m	2.0 W
LuLeey	Marvell CUX3510	SFP+1.25G/2.5G/5G/10G	80m	2.4W
LuLeey	Marvell CUX3610	SFP+1.25G/2.5G/5G/10G	30m	1.45W
LuLeey	Marvell CUX3610	SFP+1.25G/2.5G/5G/10G	80m	1.5W
LuLeey	Marvell CUX3610	SFP+1.25G/2.5G/5G/10G	100m	1.65W
LuLeey	Marvell AQR113C	SFP+1.25G/2.5G/5G/10G	30m	2.5W

Note：The lower the power consumption, the lower the operating temperature.

The CUX3610 chip was sold out，expected to be available in June 2026.

Features

Plug and Play.
Suitable for high and low temperatures.
High quality chip
Full Compatibility ,default for Cisco, Fortinet, Ubiquiti, Netgear, D-Link, TP-Link, Linksys, Broadcom, Edge-core, EMC, F5, Meraki, Norkia, QTC, Supermicro, and Other Open Switches
Max. Power Consumption less 2.5W
Tested in Targeted Switches for Superior Performance, Quality, and Reliability
Terminated RJ45 Connectors, Allowing 10G Bandwidth over Existing Infrastructure
Hot Pluggable SFP+ MSA Compliant

Specification

Model	10GBASE-T
Data Rate	10G/5G/2.5G/1.25G
Packaging	SFP+
Working voltage	3.3V
cable	10 Gigabit Ethernet over Cat 6a
Working temperature	0 °C ~+70 °C
Cable Distance	30M/80M/100M
Support DDM	Yes
Size	60x14x14mm

Additional information

Weight	0.05 kg
Dimensions	N/A
Insert port	RJ45
Data rate of SFP Module	10G
Distance (Chips)	30m(Marvell CUX3510), 80m(Marvell CUX3510), 30m(Marvell 88X3310), 80m(Broadcom BCM84891L), 100m(Broadcom BCM84891L), 80m(Marvell CUX3610), 100m(Marvell CUX3610)
Compatible brands	Alcatel-Lucent, Arista, Brocade, Cisco, Extreme, General, H3C, HPE-Aruba, Huawei, Intel, Juniper, Mellanox, Mikrotik, other(note brand when checkout), TPlink, Ubiquiti(UBNT), ZTE

Reviews (14)

14 reviews for 10GBase-T SFP+ to RJ45 Copper Module 30m/80m/100m,sfp module

5.0

Based on 14 reviews

5 star	100	100%
4 star		0%
3 star		0%
2 star		0%
1 star		0%

Anonymous – March 1, 2026

Rated 5 out of 5

0

0
Eric F. – December 1, 2025

Rated 5 out of 5
The 10GBase-T transceiver is excellent! This is running at half the power consumption and half the heat output of my previous unit, while also costing about half the price. Performance testing has gone will and this SFP+ transceiver is now running 24/7 without fail.

0

0
osth – August 9, 2024

Rated 5 out of 5
flavor: 80m, mikrotik (BCM84891L)

Confirmation that this module is recognised and working at 10G in MikroTik CSS326 Switch and in MikroTik CRS326. Temperature is 60°C without fan and 40°C with fan.

Additional note: to be recognised by these switches the module pretends to be a 850nm fiber transmitter 🙂

0

0
Derrick Sclafani – June 1, 2023

Rated 5 out of 5

0

0
Sigmund Bruckmann – June 1, 2023

Rated 5 out of 5
Received but not tested yet

0

0
Marlen Akhmetov – May 19, 2023

Rated 5 out of 5
Very good! Works perfectly with QNap

0

0
Ellie Julius – April 4, 2023

Rated 5 out of 5
This is working perfectly with a Hisource 4 port 2.5 Gbe switch and a Tp-link Pci Sfp+10g 10gb Pci Express Network Card in my Unraid server.
The only difficut part was configuring Unraid!!

0

0
Vladimiro De Angelo – February 25, 2023

Rated 5 out of 5

0

0
Kawano Tanyu – February 2, 2023

Rated 5 out of 5

0

0
Graham Rankin – January 16, 2023

Rated 5 out of 5
Great product! Bought for one half of the Moscow price. Delivery in a couple of weeks to Moscow. The assembly quality is high. The seller immediately asks what product do you buy for?
Tested at various speeds when installed in QNAP with Intel x710da4 PCI-E expansion cards. Everything Works fine. This can and should be bought. Will be satisfied. The developers are great! Thank you all!

0

0
Aasiyah Haney – January 2, 2023

Rated 5 out of 5

0

0
Wendi Raver – October 1, 2022

Rated 5 out of 5

0

0
Savannah Brotherton – June 14, 2022

Rated 5 out of 5

0

0
Cassey Odle – May 9, 2022

Rated 5 out of 5
I have a switch 10GbE us-16-xg and this adapter worked on 2.5 Gigabit in 1,5 meter away Cat6 cable.
