LC UPC Adjustable Attenuator
GBP £13.75
- LC UPC Adjustable Attenuator Precise attenuation: <=+/-0.5db
- Wavelength parameters: single mode 1310~1550nm
- Return loss: >=55dB
- Ferrule type: ceramic
- Working temperature: -40~80 degrees Celsius
- Storage temperature: -55~85 degrees Celsius
Guaranteed Safe Checkout
Description
Features
- LC UPC Adjustable Attenuator Good repeatability, good wear resistance, and good temperature stability.
- The average additional loss is less than 0.2dB, and the return loss is high.
- The number of plug-in and unplug uses is greater than 1000 times.
Specification
| Brand Name | luleey |
| Product Name | LC UPC Adjustable Attenuator |
| Precise attenuation | <=+/-0.5dB |
| Attenuation db | 0-30dB |
| Wavelength parameters | single mode 1310~1550nm |
| Return loss | greater than or equal to 60dB |
| Ferrule type | ceramic |
| Working temperature | -40~80 degrees Celsius |
| Storage temperature | -55~85 degrees Celsius |
Additional information
| Weight | 0.1 kg |
|---|---|
| Dimensions | 10 × 10 × 10 cm |
| adapter-type |
LCUPC to LCUPC |
