1GE CATV ONU Overview

The 1GE CATV ONU is a compact XPON optical network unit designed to deliver Gigabit Ethernet and CATV video services over a single FTTH fiber connection.

It supports automatic GPON and EPON identification, allowing the ONU to operate with compatible GPON or EPON OLT networks without requiring a different hardware model. The PON interface uses an SC/APC connector with 1310nm upstream and 1490nm downstream wavelengths, while the integrated CATV receiver supports a 1550±10nm optical video signal.

One 10/100/1000Mbps RJ45 Ethernet port provides Gigabit network access for a router, computer, switch, or other Ethernet device. The separate 75Ω CATV RF interface converts the received 1550nm optical CATV signal for connection to compatible television distribution equipment.

The ONU supports Web configuration, IGMP Snooping, and automatic MDI/MDIX operation. It is suitable for FTTH deployments that require broadband data and traditional CATV service without Wi-Fi or additional Ethernet ports.

The default firmware mode is SFU. HGU firmware can be supplied on request. Actual OLT and ISP compatibility depends on the required authentication method, ONU profile, service VLAN, and network configuration, so the OLT model and authentication requirements should be confirmed before replacing an ISP-provided ONU.

Key Features

• XPON dual-mode GPON/EPON operation
• Automatic GPON and EPON identification
• 1× Gigabit Ethernet RJ45 port
• 1× 1550nm CATV RF output
• SC/APC PON optical interface
• Up to 20km PON transmission distance
• Web-based configuration
• IGMP Snooping support
• Automatic MDI/MDIX
• SFU firmware by default
• HGU firmware available on request
• Designed for FTTH broadband and CATV services

Applications

• FTTH broadband access
• GPON subscriber networks
• EPON subscriber networks
• CATV over fiber
• Residential Internet + TV service
• SOHO broadband access
• ISP and WISP customer premises
• Telecom and cable operator networks
• PON laboratory testing

Technical Specifications
