INS2UM2GF8GT-8POE,10-port POE industrial Ethernet switch, with 2 Gigabit fiber ports and 8 Gigabit POE copper ports

105,25 EUR €

SKU: INS2UM2GF8GT-8POE Category: Tags: ,

*Support intelligent power supply, power shortage priority protection VIP port
*Support long distance 250 meters transmission
*Optical and electrical dual uplink design to meet dual uplink output requirements
*Support IEEE 802.3 at/af PoE power supply standard
*Provides two-block dip switch function (vlan port isolation, forced 10M)
*EMC: 15kv air discharge, 8kv contact discharge, 4kv port lightning protection, 4kv power supply lightning protection.
*IP40 protection level, industrial grade standard
*vip channel 1-2 ports (QOS priority)

Guaranteed Safe Checkout

Description

Specification

Model Num INS2UM2GF8GT-8POE
Brand LuLeey
Product Name INS2UM2GF8GT-8POE,10-port POE industrial Ethernet switch, with 2 Gigabit fiber ports and 8 Gigabit POE copper ports
Size 116mm*142mm*48mm
Back plane bandwidth 20 Gbps
Installation method DIN rail mounting
POE Support
web management no
RJ45 Ports 10/100/1000M
SFP Ports SFP 1000M
IP Rating IP40
Power Input Dual Power Supply
Power DC48-57V
PoE Budget/Single  Port 　
Shell Material Aluminum Shell
Working Temperature  -40~85˚C
Storage Temperature  -40~85˚C
LULEEY INS2UM2GF8GT-8POE DATASHEET

Features

Industrial switches engineered for extremes | LuLeey

Industrial switches pass 16 industrial-grade test procedures to meet EMC Level 4 requirements.

Temperature Protection

-40℃～85℃ working environment

Industrial Grade Chips

All ports have wire-speed forwarding capability
Supports Auto MDI/MDIX (port rollover) function

EMC LEVEL 4

15kv air discharge, 8kv contact discharge, 6kv port lightning protection, 4kv power supply lightning protection

IP40

Adopting industrial grade IP40 protection level, stable and worry-free operation, safe and reliable

Power Supply Protection

Voltage range DC 9~48V, dual power supply redundancy

Port Isolation Switch

Provides two-position dip switch functionality (storm suppression and vlan port isolation)

DIN
Additional information
Weight 0,85 kg
Dimensions 10 × 10 × 10 cm
Industrial Switch Fiber Port

SFP 1000M
Industrial Switch RJ45 Port

10/100/1000M
Industrial Switch PoE

PoE
