S09 High Precision Optical Fiber Cleaver

Name: S09 High Precision Optical Fiber Cleaver - LuLeey.com | One-stop Optical Fiber Product Supplier
Availability: InStock

Price range: GBP £19.25 through GBP £84.00

Fiber Optic Cleaver Option

SKU: N/A Category: Fiber Cleavers & Fiber Strippers Tags: Optical Fiber Cleaver, S09

Precision Cutting: Provides a cleave with a cutting angle of less than 0.5° for optimal fiber preparation for fusion splicing.
Built-in fiber holder: The fiber cleaver can hold 250µm,900µm and 3.0mm single fiber with a readable scale for accurate cleave lengths from 5 to 25mm.
Versatile use: Ideal for field splicing applications, splicing trucks, laboratories, fiber technicians, fiber splicers, and anyone that needs to cleave a fiber optic cable prior to performing a fusion splice.
Durability: Lightweight and rugged design increased durability. Also easy to disassemble and operate, allowing easy blade replacement.
Blade life : 48000 times(3000*16) .

Guaranteed Safe Checkout

Description

The Tools S09 Precision Fiber Cleaver is designed to provide precise cleavage and preparation of fibers for splicing for 250 µm, 900 µm and 3.0mm coated fibers
Features a built-in fiber bin
Long life of 48,000 cuts with 16 position blades
Scale bracket for precise cut lengths from 8 to 20 mm (0.31″ to 0.78″)
Provides cleave with a cleave angle of less than 0.5° for optimal fiber preparation for splicing
Lightweight and sturdy design for long-term durability

Brand Name	LuLeey
Origin	Mainland China
Product Name	S09 High Precision Optical Fiber Cleaver
Material	Magnesium alloy
Color	Gold
Product Dimensions	605951mm
Cladding diameter	80-150μm
Cutting length	Single core fiber 8-20mm
Suitable for fiber optic cable	Single core fiber 250μm, 900μm, 3.0mm, indoor leather cable
Item Weight	0.3kg
Blade life	3000*16;Cutting 1000 times to adjust the height once, each scale can be adjusted 3 times the height, a total of 16 scales.
Blade automatic return:	Yes
Average Cleaving Angle	＜0.5°
Anti-slip Rubber Mats	Support
Hexagon Socket Tool	Included
Waste Fiber Box	Included
Protective Case	Included
