10g media converter support two types of media network connections, such as 10GBase-T and 10GBase-R. Designed with 10Gbase Ethernet PHY chip, it can smoothly connect two types of network segments. The transceiver can be used as a stand-alone unit or as an embedded module in a 19 “converter rack for use in the central wiring room. The production of the product is carried out completely in accordance with the standard process,which effectively guarantees the reliability and safety of the product. This series of products can realize the conversion of data signals in two different transmission media of twisted pair and optical fiber in the new high-speed Ethernet optical fiber network, meeting the needs of long-distance and high-speed Ethernet users, and is ideal for users of telecommunications, broadcasting, and broadband networks. Fiber optic transmission equipment.
- Copper port can adapt to parallel/crossover connection;
- IEEE802.3x flow control supporting full duplex;
- Support half-duplex back pressure flow control;
- Optical wavelength 850nm, 1310nm, 1550nm optional;
- Can work under the temperature of 0℃~60℃;
Standard
10g media converter 1000Base-T, 2.5GBase-T, 5Gbase-T, 10Gbase-T, 10GBase-R
Electric port characteristics
Interface type : RJ-45
Rate:100/1000Base-T,2.5/5/10GBase-T Auto
Cable type: UTP-6e or higher
Transmission distance:0-~100m
Optical port characteristics
Interface type:SFP+
Rate:10Gbps
Multimode: 50/125um
Single mode: 9/125um
Transmission distance: 300m~80Km
LED :
PWR, Link/Act(FX), SD, Link, Act, 10G
Power requirement
Input voltage :DC12V
Physical properties
Shell: iron shell
Size : 94mm*70mm*26mm
Weight : 0.32KG
Installation method: desktop
Environmental restrictions
Operating temperature: 0~ 60°C (32 ~ 140°F)
Relative humidity of the environment: : 5 ~ 80% (non-condensing)
10GBaseFX | ||
Multimode | Single mode | |
wavelength | 850 nm | 1310 |
Maximum transmit | 1 dBm | 0 dBm |
Minimum transmit | -6 dBm | -6 dBm |
Receiving sensitivity | -12 dBm | -13 dBm |
Link budget | 6 dBm | 7 dBm |
Typical distance | 300m | 10 km |
Saturation | -3 dBm | -3 dBm |
50/125um, 800 MHz*km 9/125 um |
