SC to LC Fiber Adapter Overview

The SC to LC Fiber Adapter is a single mode male-to-female hybrid adapter designed to connect an SC/UPC equipment interface to an LC/UPC fiber connector.

Its SC/UPC male side connects directly to a compatible SC/UPC female equipment port, while the LC/UPC female side accepts a standard LC/UPC male connector. This fixed interface configuration provides a convenient conversion solution when optical equipment and existing fiber cables use different connector types.

The adapter converts the standard 2.5mm SC ferrule interface to the compact 1.25mm LC interface. A ceramic alignment sleeve helps maintain accurate fiber positioning and stable optical transmission, with insertion loss below 0.3dB and return loss of at least 50dB.

Its compact plug-and-play construction allows direct interface conversion without replacing the equipment port, installing a dedicated hybrid patch cable, or performing fusion splicing. It is suitable for optical power meters, visual fault locators, optical light sources, fiber test equipment, communication devices, and telecom network maintenance.

Both optical interfaces should be inspected and cleaned before installation. Dust, oil, or damaged connector end faces can increase insertion loss and reduce test accuracy.

Key Features

• Fixed SC/UPC male to LC/UPC female configuration
• Single mode 9/125μm fiber support
• 2.5mm to 1.25mm ferrule conversion
• UPC-to-UPC polish combination
• Ceramic sleeve for precise optical alignment
• Insertion loss <0.3dB
• Return loss ≥50dB
• Working wavelength from 1200nm to 1600nm
• More than 1000 insertion cycles
• Compact and reusable construction
• No fusion splicing required
• Simple plug-and-play installation

Applications

• Optical power meters
• Visual fault locators
• Optical light sources
• Fiber fault detection equipment
• Optical communication devices
• FTTH and FTTX maintenance
• Telecom transmission networks
• Laboratory optical testing
• Equipment interface conversion

Technical Specifications
